5 Mega pixels resolution and 1/2.5 inch CCD produce high definition image. With CMOS leaner array, all tiny subjects are shown clearly.
One power cable and one data line will realize data transmission easily. Neither hardware nor computer configuring is required.
Infrared control, easy-operating and no electromagnetic radiation, is much safer and more stable. Its hardware compatibility is maturest and widest.
Target area sizecon controlled by auto exposure is changed easily via moving the mouse lightly. Any area is shown clearly.
The most compact imaging module (L135 mm x W74mm x H48.5mm) makes it installed conveniently and operated easily.
Simple design style and friendly interface help operators handle it quickly.
RAW/PNG/BMP/JPG output file format are compatible with most of the third-party software.
Professional patient information management platform is important to conduct centralized management for patient information. This platform support integrated function print.
Practical image processing can meet most of operators demand.
Operator will not miss any image via special snapshot'warning sound.
| Image Sensor | 1/2.5" (4:3) Progressive High-Speed CMOS |
| Image Size | Up to 5meg (2592x1944) pixels |
| Cell Size | 2.2μm x 2.2μm |
| Resolution Dept | 8bit RGB Bayer Pattern |
| Transmit Method | USB 2.0 |
| Transmit Speed | Up to 480Mbps |
| Frame Rate | Up to 30 Fps |
| Out Put Format | BMP, JPEG, PNG, RAW |
| Photograph | External Trigger or Software Trigger (Wireless: IRDA) |
| Dimension | L135mm x W74mm x H48.5mm |
| Power Consumption | Less than 1.5W |
